996
Marker
X-axis scale (formerly Readout)
Accesses a menu that enables you to affect how the X-axis information for the selected marker is
displayed in the marker area (top-right of display) and the active function area of the display, and how
the marker is controlled. The available settings for the X-axis scale are Frequency, Period, Time, and
Inverse Time.
See “More Information” on page 997.
Couplings The act of specifying the selected marker’s reference marker makes the
selected marker a Delta marker. If the reference marker is off it is turned on in
Fixed mode at the delta marker location.
Preset The preset default “Relative To” marker (reference marker) is the next higher
numbered marker (current marker +1). For example, if marker 2 is selected,
then it’s default reference marker is marker 3. The exception is marker 12,
which has a default reference of marker 1.
Set to the defaults by using
Restore Mode Defaults. This is not reset by
Marker Off, All Markers Off, or Preset.
State Saved Saved in instrument state. Not affected by Marker Off and hence not affected
by Preset or power cycle.
Min 1
Max 12
Status Bits/OPC dependencies none
Default (selected when
Restore Mode Defaults is pressed): next higher
numbered marker or 1 if marker 12.
Initial S/W Revision Prior to A.02.00
Key Path
Marker, Properties
Remote Command :CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:X:READout
FREQuency|TIME|ITIMe|PERiod
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:X:READout
?
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:X:READout
:AUTO ON|OFF|1|0
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:X:READout
:AUTO?
Example CALC:MARK3:X:READ TIME sets the marker 3 X-axis scale to Time.
Notes This command causes the specified marker to become selected.
Notes This command causes the specified marker to become selected.
