ACP Measurement
Meas Setup
Offset Side
Enables you to turn off (not use) specific offsets.
• NEGative - negative (lower) sideband only
• BOTH - both of the negative (lower) and positive (upper) sidebands
• POSitive - positive (upper) sideband only
Method for Offset
This key allows you to turn RRC filtering of each offset on or off. The value (roll off) for the filter will
be set to the value of the Filter Alpha parameter.
Range Absolute|Relative|Abs AND Rel (fail if both fail)|Abs OR Rel (fail if either
fails)
Backwards Compatibility SCPI [:SENSe]:MCPower:OFFSet[1]|2:LIST:TEST
Initial S/W Revision Prior to A.02.00
Modified at S/W Revision A.02.00, A.03.00, A.04.00
Modified at S/W Revision A.04.00
Key Path
Meas Setup, Offset/Limits
Mode WCDMA, C2K, 1xEVDO, LTE
Remote Command [:SENSe]:ACPower:OFFSet[1]|2:LIST:SIDE
NEGative|BOTH|POSitive,NEGative|BOTH|POSitive,NEGative|
BOTH|POSitive,NEGative|BOTH|POSitive,NEGative|BOTH|POSi
tive,NEGative|BOTH|POSitive
[:SENSe]:ACPower:OFFSet[1]|2:LIST:SIDE?
Example ACP:OFFS:LIST:SIDE BOTH
ACP:OFFS:LIST:SIDE?
Notes OFFSet1 is for BTS, 2 for MS. Default is BTS.
You must be in the W-CDMA mode, cdma2000 mode, 1xEVDO mode or LTE
mode to use this command. Use :INSTrument:SELect to set the mode.
If you set POS or NEG in an offset, result of the inactive side will return –999.
Preset BOTH, BOTH, BOTH, BOTH, BOTH, BOTH| BOTH, BOTH, BOTH,
BOTH, BOTH, BOTH
State Saved Saved in instrument state.
Range Neg|Both|Pos
Initial S/W Revision A.03.00
Key Path
Meas Setup, Offset/Limits
