186
System Functions
Mode Preset
Restore Mode Defaults
Resets the state for the currently active mode by resetting the mode persistent settings to their factory
default values, clearing mode data and by performing a Mode Preset. This function will never cause a
mode switch. This function performs a full preset for the currently active mode; whereas, Mode Preset
performs a partial preset. Restore Mode Defaults does not affect any system settings. System settings are
reset by the Restore System Defaults function. This function does reset mode data; as well as settings.
*RST *RST not possible (Mode Preset
with Single)
Restore Input/Output
Defaults
:SYSTem:DEFault INPut System Menu; Restore
System Default Menu
Restore Power On Defaults :SYSTem:DEFault PON System Menu; Restore
System Default Menu
Restore Alignment Defaults :SYSTem:DEFault ALIGn System Menu; Restore
System Default Menu
Restore Miscellaneous
Defaults
:SYSTem:DEFault MISC System Menu; Restore
System Default Menu
Restore All System Defaults :SYSTem:DEFault [ALL]
:SYSTem:PRESet:PERSistent
System Menu; Restore
System Default Menu
User Preset :SYSTem:PRESet:USER User Preset Menu
User Preset All Modes :SYSTem:PRESet:USER:ALL User Preset Menu
Power On Mode Preset :SYSTem:PON:TYPE MODE System Menu
Power On User Preset :SYSTem:PON:TYPE USER System Menu
Power On Last State :SYSTem:PON:TYPE LAST System Menu
Key Path:
Mode Setup
Remote Command: :INSTrument:DEFault
Example: :INST:DEF
Notes: Clears all pending OPC bits. The Status Byte is set to 0.
A message comes up saying: “If you are sure, press key again”.
Couplings: A Restore Mode Defaults will cause the currently running measurement to be
aborted and causes the default measurement to be active. It gets the mode to a
consistent state with all of the default couplings set.
Initial S/W Revision: Prior to A.02.00
Type Of Preset SCPI Command Front Panel Access
