Marker
at the indicator point of the marker (that is, the center of the X or the bottom tip of the diamond. The lines
are blue in color.
If the marker is off screen the lines should be extended from the marker so that they go thru the screen
area if possible. This is really useful for off screen Fixed markers as it lets you see their amplitude even
though they are off the X-axis.
Marker Table
When set to On the display is split into a measurement window and a marker data display window. For
each marker which is on, information is displayed in the data display window, which includes the marker
number, control mode, trace number, X axis scale, X axis value, and the Y-axis result. Additional
information is shown for markers which have marker functions turned on.
Turning the Marker Table on turns the Peak Table off and vice versa.
Marker Count
Accesses the marker count menu.
Key Path Marker, Properties
Remote Command :CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:LINes[:ST
ATe] OFF|ON|0|1
:CALCulate:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:LINes[:ST
ATe]?
Example :CALC:MARK2:LIN:ON turns Lines on for marker 2.
Couplings Sending the remote command causes the addressed marker to become
selected.
Preset OFF
State Saved Saved in State
Initial S/W Revision Prior to A.02.00
Key Path
Marker
Remote Command :CALCulate:MARKer:TABLe[:STATe] OFF|ON|0|1
:CALCulate:MARKer:TABLe[:STATe]?
Example CALC:MARK:TABL ON turns on the marker table.
Preset OFF
State Saved Whether the marker table is on is saved in instrument state
Initial S/W Revision Prior to A.02.00
Key Path
Marker
