414
ACP Measurement
Meas Setup
Method for Carrier
Accesses the carrier configuration method settings.
Remote Command [:SENSe]:ACPower:CARRier[1]|2:LIST:BANDwidth[:INTegrati
on] <freq>, …
[:SENSe]:ACPower:CARRier[1]|2:LIST:BANDwidth[:INTegrati
on]?
Example ACP:CARR2:LIST:BAND 25kHz
ACP:CARR2:LIST:BAND?
Notes In the WCDMA mode, the preset/default value is defined as 3.84 MHz. But
internally, 4.6848 MHz is used as the default value.
Carrier sub op code. 1 for BTS, 2 for MS. Default is BTS.
When setting these values remotely, the position in the list sent corresponds to
the carrier. Missing values are not permitted, therefore if you want to change
values 2 and 6 you must send all values up to 6. Subsequent values will
remain unchanged, unless the number of values sent is greater than the
number of carriers, then subsequent values will be ignored.
You must be in the mode that includes ACP measurements to use this
command. Use :INSTrument:SELect to set the mode.
Couplings Coupled to the number of carriers. When the SCPI command is sent, the
number of carriers is set to the number of entries in the parameter list.
Preset WCDMA: 3.84 MHz
WIMAX OFDMA: 10 MHz
C2K: 1.23 MHz
TD-SCDMA: 1.28 MHz
1xEVDO: 1.23 MHz
LTE, LTETDD: 4.515 MHz|4.5 MHz
State Saved Saved in instrument state.
Min 10 Hz
Max 1 GHz
Backwards Compatibility SCPI [:SENSe]:ACPower:BANDwidth:INTegration
[:SENSe]:ACPower:BWIDth:INTegration
[:SENSe]:ACPower:CARRier[1]|2:LIST:BWIDth[:INTegration]
[:SENSe]:MCPower:CARRier[1]|2:LIST:BANDwidth[:INTegration] (PSA
Power Suite)
[:SENSe]:MCPower:CARRier[1]|2:LIST:BWIDth[:INTegration] (PSA Power
Suite)
Key Path
Meas Setup, Carrier Setup, Configure Carriers
