Source (Internal)
ARB
Allows you access to the ARB sub-menus.
ARB
Allows you to toggle the state of the ARB function. When the ARB is On, a “MOD” annunciator is
displayed in the system settings panel. When the ARB is turned Off, the MOD annunciator is cleared
Select Waveform
Allows you to access to the waveform selection sub-menus.
Initial S/W Revision: A.05.00
Key Path:
Source, Modulation Setup
Initial S/W Revision: A.05.00
Key Path:
Source, Modulation Setup, ARB
Remote Command: :SOURce:RADio:ARB[:STATe] ON|OFF|1|0
:SOURce:RADio:ARB[:STATe]?
Example: SOUR:RAD:ARB OFF
SOUR:RAD:ARB?
Notes: If the ARB is ON, a user then loads or deletes another file to ARB memory,
the playing waveform segment may not keep phase continuity during the ARB
memory operation. The waveform will be replayed after the ARB operation is
finished.
Dependencies: This setting is for independent mode and has no effect on 3.3.8 list sequencer
mode. Setting 7.1Sequencer to On will put source enter list sequencer mode,
and even if ARB state is On, the ARB file will not be played. Setting
7.1Sequencer to Off will make source leave list sequencer mode, and this
setting will take effect immediately.
The ARB can only be turned on when there is a waveform file selected for
playback. On the GUI If no waveform is selected, this key is grayed out. If
you send the SCPI command to turn the ARB on with no waveform selected
for playback, the ARB state remains OFF and an error is generated. “-
When you try to recall a certain set of states in which the selected waveform is
not in ARB memory and the ARB state is On, errors are reported
Preset: Off
Range: On | Off
Initial S/W Revision: A.05.00
