1220
Source (Internal)
Initiate Sequence
Pressing this key arms the sequence for single execution. Once the sequence is armed the source begins
the sequence as soon as the trigger is received. If the trigger is set to Free Run, the sequence starts
immediately.
Remote Software Trigger (Remote command Only)
During execution of a list sequence, the sequence will halt and wait at any step that has Step Trigger set
to “Bus”. Sending this command will trigger the step and continue the sequence.
Notes: When the sequencer is set to ON, the list sequencer controls the output of the
source.
Couplings: When in Sequence Analyzer mode and the list sequencer state is Off, Include
Source is forced to No, and the Include Source key is grayed out.
When in Sequence Analyzer mode and the list sequencer state is On, Include
Source is available to set. And, an ARB memory related operation, like load
or delete will be rejected.
Preset: Off
Range: On | Off
Initial S/W Revision: A.05.00
Key Path:
Source, List Sequencer
Remote Command: :SOURce:LIST:TRIGger[:IMMediate]
Example: SOUR:LIST:TRIG
Notes: When in Sequence Analyzer mode and Include Source is Yes, the Initiate list
sequencer operation is rejected, and the key is grayed out, since source list
sequence request is sent to physics via Parallel batch by sequence analyzer.
If the file needed by the sequencer is not already in ARB memory, the
sequence cannot be initiated and an error will be generated.
There is a blocking SCPI query which can be used to query if source list
sequence being initiated successfully or not. (see “Query List Sequence
Initiation Armed Status (Remote Command Only)” on page 1258 Query
Source List Sequence Armed Status)
Dependencies: Under the Sequence Analyzer Mode, if Meas Setup->Include Source is set to
YES, Source->List Sequencer->Initiate Sequence is disabled.
Initial S/W Revision: A.05.00
Remote Command: :SOURce:LIST:TRIGger:INITiate[:IMMediate]
Example: SOUR:LIST:TRIG:INIT
Initial S/W Revision: A.05.00
