Source (Internal)
Source (Internal)
Opens a menu of keys that access various source configuration menus and settings. In the test set,
pressing this key also causes the central view area to change and display the Source Control Main view.
RF Output
This parameter sets the source RF power output state.
Amplitude
Allows you to access the Amplitude sub-menu.
Key Path: Front-panel key
Key Path: Source
Remote Command: :OUTPut[:EXTernal][:STATe] ON|OFF|1|0
:OUTPut[:EXTernal][:STATe]?
Example: OUTP OFF
OUTP?
Notes: The EXTernal node is shown in RD text so the SCPI remains the same
between internal and external source control. However, for EXT we do not
wish to document this node to the customer since we are controlling the
internal source rather than the external source.
This setting is for the independent mode and has no effect on the “List
Sequencer” on page 1219. If the “Sequencer” on page 1219 is set to ON, the
list sequencer controls the source output and this key will be grayed-out. And
this setting will be none-forceful grey out on front panel to indicate
out-of-scope. Non-forceful means user still can change this setting by SCPI
but cannot change on front panel. When set to OFF will make source leave list
sequencer and this setting will be black out and take effect immediately.
When the RF Output is ON, an “RF” annunciator is displayed in the system
settings panel. When the RF Output is turned Off, the RF annunciator is
cleared. If the “Sequencer” on page 1219 is set to ON, the “RF” annunciator
will be replaced by “SEQ” in the system settings panel, indicating that the
output is controlled by the list sequencer.
Preset: Off
Range: On | Off
Initial S/W Revision: A.05.00
Key Path:
Source
