Mode
TD-SCDMA with HSPA/8PSK
Selects the TD-SCDMA mode for general purpose measurements of signals following this standard.
There are several measurements available in this mode.
If you are using the Help feature, this mode must be currently active to access its detailed information. If
it is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
W-CDMA with HSPA+
Selects the W-CDMA with HSPA+ mode for general purpose measurements of signals following this
standard. There are several measurements available in this mode.
If you are using the Help feature, this mode must be currently active to access its detailed information. If
it is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Global Settings
Opens up a menu that allows you to switch certain Meas Global parameters to a Mode Global state.
These switches apply to all Modes that support global settings. No matter what Mode you are in when
you set the “Global Center Frequency” switch to on, it applies to all Modes that support Global Settings.
Global Center Freq
The software maintains a Mode Global value called “Global Center Freq”.
When the
Global Center Freq key is switched to On in any mode, the current mode’s center frequency
is copied into the Global Center Frequency, and from then on all modes which support global settings
use the Global Center Frequency. So you can switch between any of these modes and the Center Freq
will remain unchanged.
Adjusting the Center Freq of any mode which supports Global Settings, while
Global Center Freq is
Initial S/W Revision: A.05.01
Key Path:
Mode
Example: INST:SEL TDSCDMA
INST:NSEL 211
Initial S/W Revision: Prior to A.02.00
Key Path:
Mode
Example: INST:SEL WCDMA
INST:NSEL 9
Initial S/W Revision: Prior to A.02.00
Key Path:
Front Panel Key
Initial S/W Revision: Prior to A.02.00
