System Functions
System
Show Source Self Test Results contents (Remote Command Only)
A remote command is available to obtain the contents of the Show Souce Self Test Results screen (the entire
contents, not just the currently displayed page).
RFIO Self Test REsults
Provides a display of last RFIO test results for embedded MPA of E6607C, the display should appear listing model
number, serial number and test time at the top of display, and then list test date/time, test name, measured value,
valid range and pass/fail of each RFIO test item, the tabular data should be directly printable.
NOTE This function is NOT available on EXT E6607A and E6607B models.
The example of RFIO self test result display is as following:
Remote Command: :SYSTem:TEST:WCTS:SOURce:RESult?
Example: SYST:TEST:WCTS:SOUR:RES?
Notes: The output is an IEEE Block format of the Show Source Self Test Results
contents. Each line is separated with a new-line character.
Initial S/W Revision: A.12.50
Key Path:
System, Diagnostics, Self Test,Show Results
Remote Command: :SYSTem:TEST:WCTS:SHOW:RESult MPADapter
Example: SYST:TEST:WCTS:SHOW:RES MPAD
Initial S/W Revision: A.12.50
RFIO Self Test Results
Produce Number: E6607C
Serial Number: MY51380437
Instrument S/W: 11/16/2012 2:51:19 PM
CarrierClockTest 16:13:56
Date Time(GMT) Name MeasValue ValidRange Result
11/23/2012 16:13:57 Dig FPGA 100 MHz 1.000 1.000 - 1.000 Pass
11/23/2012 16:13:57 Feldspar CCLK 1.000 1.000 - 1.000 Pass
11/23/2012 16:13:57 Feldspar LVDS 1.000 1.000 - 1.000 Pass
11/23/2012 16:13:57 Dig FPGA LVDS 1.000 1.000 - 1.000 Pass
11/23/2012 16:13:57 Dig FPGA 200 MHz 1.000 1.000 - 1.000 Pass
DetectorTest
Date Time(GMT) Name MeasValue ValidRange Result
