1241
Source (Internal)
Frequency
Allows you to specify a frequency value for the current step.
Couplings: The channel number is coupled to the step frequency value. When the step
frequency value is changed, the channel number will increase or decrease to
match the new step frequency. If the step frequency is not at an exact match
for a channel number, the nearest channel number is displayed, along with a
greater than, or less than sign to indicate the frequency is above or below the
channel number.
Preset: 1
Min: 0 (Please refer to for valid ranges.)
Max: 10838 (Please refer to for valid ranges.)
Initial S/W Revision: A.05.00
Key Path:
Source, List Sequencer, List Sequencer Setup
Remote Command: :SOURce:LIST:STEP[1]|2|3…1000:SETup:CNFRequency
<double>
:SOURce:LIST:STEP[1]|2|3…1000:SETup:CNFRequency?
Example: SOUR:LIST:STEP2:SET:CNFR 1GHz
SOUR:LIST:STEP2:SET:CNFR?
Notes: SCPI is supported after A.09.40.
This SCPI is used to setup channel number or frequency setting, according to
current Radio Band setting. If Radio Band is “NONE”, then it’s frequency. If
Radio Band is not “NONE”, then it’s channel number.
Couplings: The frequency value is coupled to the channel band and number for the step,
such that updates to the radio band and channel number will update the
frequency value to the corresponding absolute frequency. The reverse is also
true, changing the frequency value causes the value of the channel number to
be updated.
Preset: 1.00 GHz
Min: 10.00 MHz
Max: Hardware Dependant:
Option 503 = 3.6 GHz
Option 504 = 3.8 GHz
Initial S/W Revision: A.05.00
