329
Channel Power Measurement
Marker
Relative To
Sets the reference marker to which the selected marker is relative.
Couple Markers
When this function is active, moving any marker causes an “equal X Axis movement” of every other
marker that is not set to
Off. By “equal X Axis movement” we mean that we preserve the difference
between each marker’s X Axis value (in the fundamental x-axis units of the trace that marker is on) and
the X Axis value of the marker being moved (in the same fundamental x-axis units).
This may result in markers going off screen.
Key Path: Marker, Properties
Mode: WCDMA, C2K, WIMAX OFDMA, 1xEVDO, LTE, LTETDD, WLAN
Remote Command: :CALCulate:CHPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:R
EFerence <integer>
:CALCulate:CHPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:R
EFerence?
Example: CALC:CHP:MARK:REF 5
CALC:CHP:MARK:REF?
Notes: A marker cannot be relative to itself so that choice is grayed out, and if sent
from SCPI generates error –221: “Settings conflict; marker cannot be relative
to itself.”
When queried, a single value is returned (the specified marker numbers
relative marker).
Preset: 2|3|4|5|6|7|8|9|10|11|12|1
State Saved: Saved in instrument state.
Min: 1
Max: 12
Initial S/W Revision: Prior to A.02.00
Modified at S/W Revision: A.02.00, A.03.00
Key Path:
Marker
Mode: WCDMA, C2K, WIMAX OFDMA, 1xEVDO, LTE, LTETDD, WLAN
Remote Command: :CALCulate:CHPower:MARKer:COUPle[:STATe] ON|OFF|1|0
:CALCulate:CHPower:MARKer:COUPle[:STATe]?
Example: CALC:CHPower:MARK:COUP ON
Preset: OFF
State Saved: Saved in instrument state.
