Input/Output
dBµA/m
Sets the antenna unit to dBµA/m. If this correction is turned on, and Apply Corrections is on, the Y Axis Unit will
then be forced to dBµA/m and all other Y Axis Unit selections will be grayed out.
dBpT
Sets the antenna unit to dBpT. If this correction is turned on, and Apply Corrections is on, the Y Axis Unit will then
be forced to dBpT and all other Y Axis Unit selections will be grayed out.
dBG
Sets the antenna unit to dBG. If this correction is turned on, and Apply Corrections is on, the Y Axis Unit will then
be forced to dBG and all other Y Axis Unit selections will be grayed out.
None
Selects no antenna unit for this Correction set. Thus no Y Axis unit will be forced.
Example: :MPAD:CORR:CSET2:ANT UVM
Readback: "dBµV/m"
Initial S/W Revision: A.10.00
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Properties, Antenna Unit
Example: :MPAD:CORR:CSET2:ANT UVA
Readback: " dBµA/m"
Initial S/W Revision: A.10.00
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Properties, Antenna Unit
Example: :MPAD:CORR:CSET3:ANT PTES
Readback: "dBpT"
Initial S/W Revision: A.10.00
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Properties, Antenna Unit
Example: :MPAD:CORR:CSET:ANT GAUS
Readback: " dBG"
Initial S/W Revision: A.10.00
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Properties, Antenna Unit
Example: :MPAD:CORR:CSET4:ANT NOC
