1062
Meas Setup
Type, Margin, Interpolation, Relative to CF/RL) are unchanged.
When taking a trace in order to build a limit, it will often work well to take the trace with a resolution
bandwidth wider than the expected measurement, a video bandwidth lower than the expected
measurement, and with the detector set to Max Hold or Min Hold.
Note that an upper limit is built above the trace, while a lower limit is built below the trace. If the trace is
constant, the limit should pass after being built.
Offset
Enters a menu which allows you to offset the limit trace by a specified frequency, time, or amplitude.
The offsets are immediately applied to the limit trace for display and failure calculation; the offset can
also be applied to the points in the limit line.
X Offset
Offsets the limit trace by some specified frequency (for Frequency-based limit lines) or a time (for time-based limit
lines).
Remote Command: :CALCulate:LLINe[1]|2|3|4|5|6:BUILd
TRACE1|TRACE2|TRACE3|TRACE4|TRACE5|TRACE6
Example: :CALC:LLIN2:BUIL TRACE1 builds limit line 2 based on the data in trace 1.
This will overwrite the data in the table editor.
Notes: Auto return to Edit menu.
Initial S/W Revision: A.02.00
Key Path
Meas Setup, Limits, Edit
Initial S/W Revision A.02.00
Key Path
Meas Setup, Limits, Edit, Offset
Remote Command :CALCulate:LLINe[1]|2|3|4|5|6:OFFSet:X <value>
:CALCulate:LLINe[1]|2|3|4|5|6:OFFSet:X?
<value> = <freq> if Limit X-Axis Unit is Frequency, <value> = <time> if
Limit X-Axis Unit is Time
Example :CALC:LLIN:OFFS:X –50MHZ sets the X axis offset to –50 MHz.
:CALC:LLIN:OFFS:UPD will apply the X axis offset to all points in the limit
line, then reset the X axis offset to zero.
Preset 0 Hz if Limit X-Axis Unit is Frequency
0 S if Limit X-Axis Unit is Time
State Saved Saved in State, survives Preset
Min –500 GHz
Max 500 GHz
