396
ACP Measurement
Marker
Marker X Axis Position (Remote Command Only)
Sets the marker X position in trace points. It has no effect if the control mode is Off, but is the SCPI
equivalent of entering a value if the control mode is
Normal, Delta or Fixed. The entered value is
immediately translated into the current X Axis Scale units for setting the value of the marker.
Marker Y Axis Value (Remote Command Only)
Returns the marker Y axis value in the current marker Y axis unit.
Modified at S/W Revision A.02.00, A.03.00
Mode WCDMA, C2K, WIMAX OFDMA, TD-SCDMA, 1xEVDO, LTE, LTETDD
Remote Command :CALCulate:ACPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:X
:POSition <real>
:CALCulate:ACPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:X
:POSition?
Example CALC:ACP:MARK10:X:POS 0
CALC:ACP:MARK10:X:POS?
Notes The query returns the marker’s absolute X Axis value in trace points if the
control mode is
Normal, or the offset from the marker’s reference marker in
trace points if the control mode is
Delta. The value is returned as a real
number, not an integer, corresponding to the translation from X Axis Scale
units to trace points (see “Fractional Trace Points”). If the marker is
Off the
response is not a number.
When a Marker is turned on, it is placed center of the screen on the trace.
Therefore the default value depends on instrument condition, although the
Preset/Default is defined as 500 (this value might be expected value when all
offset is on).
Dependencies Unavailable when “Meas Method” on page 433 is set to RBW.
Preset After a preset, all Markers are turned OFF, so Marker X Axis Value query will
return a not a number (NAN).
State Saved No
Min –9.9E+37
Max 9.9E+37
Initial S/W Revision Prior to A.02.00
Modified at S/W Revision A.02.00, A.03.00
Mode WCDMA, C2K, WIMAX OFDMA, TD-SCDMA, 1xEVDO, LTE, LTETDD
Remote Command :CALCulate:ACPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|12:Y?
Example CALC:ACP:MARK11:Y?
