Trigger
Trigger Slope
It is set positive to trigger on a rising edge and negative to trigger on a falling edge.
Trig Delay
Controls a time delay during which the analyzer will wait to begin a sweep after meeting the trigger
criteria. You can use negative delay to pre-trigger the instrument in time domain or FFT, but not in swept
Dependencies: This key is grayed out and Absolute Trigger Level selected if the required
hardware is not present in your analyzer and the current measurement does not
support Relative triggering.
Preset: –6 dB
GSM: –25 dB
State Saved: Saved in instrument state
Min: –45 dB
Max: 0 dB
Default Unit: dB or dBc
Backwards Compatibility SCPI: :TRIGger[:SEQuence]:RFBurst:LEVel
This legacy command is aliased to
:TRIGger[:SEQuence]:RFBurst:LEVel:RELative because the PSA had ONLY
relative burst triggering
Initial S/W Revision: Prior to A.02.00
Modified at S/W Revision: A.04.00
Key Path:
Trigger, RF Burst
Remote Command: :TRIGger[:SEQuence]:RFBurst:SLOPe POSitive|NEGative
:TRIGger[:SEQuence]:RFBurst:SLOPe?
Example: TRIG:RFB:SLOP NEG
Couplings: This same slope is used in the RF Burst selection for the trigger source in the
Trigger menu and for the period timer sync source (in the Trigger menu and in
the Gate Source menu).
Preset: POSitive
State Saved: Saved in instrument state
Backwards Compatibility SCPI: :TRIGger[:SEQuence]:FRAMe:RFBurst:SLOPe
Backwards Compatibility Notes: The legacy :TRIGger[:SEQuence]:SLOPe command affects the slopes for the
VID, LINE, EXT1, EXT2, and RFB triggers.
Initial S/W Revision: Prior to A.02.00
