Meas Setup
Edit
Opens the Table Editor for the selected limit line.
When entering the menu, the editor window (with the limit table) turns on, the selected Limit is turned
On and the amplitude scale is set to Log. The display of the trace to which the selected limit applies is
turned on (thus, traces in Blank are set to View and traces in Background are set to On). Turning on the
Limit means it’s display is on, and it’s testing mode is on as well; you should turn off any other limits
that are on if they interfere with the editing of the selected limit.
NOTE The table editor will only operate properly if the test set is sweeping, because its
updates are tied to the sweep system. Thus, you should not try to use the editor in
single sweep, and it will be slow during computer-intensive operations like
narrow-span FFT sweeps.
When exiting the edit menu (by using the Return key or by pressing a test set front panel key), the editor
window turns off, however the Limit is still on and displayed, and the amplitude scale remains
Log.
Limits are turned off by a Preset, but the Limits arrays (data) are only reset (deleted) by Restore Mode
Defaults. They survive shutdown and restarting of the test set application, which means they will survive
a power cycle.
Navigate
Lets you move through the table to edit the desired point
Frequency
Lets you edit the frequency of the current row.
Key Path Meas Setup, Limits
Couplings Turns the Limit Peaks table off.
A remote user can enter or access limit line data via
:CALCulate:LLINe[1]|2|3|4|5|6:DATA
Initial S/W Revision A.02.00
Key Path
Meas Setup, Limits, Edit
Notes There is no value readback on the key
Initial S/W Revision A.02.00
Key Path
Meas Setup, Limits, Edit
Notes There is no value readback on the key
Initial S/W Revision A.02.00
