Sweep/Control
Key Path: Sweep/Control, Gate
Remote Command: [:SENSe]:SWEep:EGATe[:STATe] OFF|ON|0|1
[:SENSe]:SWEep:EGATe[:STATe]?
Example: SWE:EGAT ON
SWE:EGAT?
Dependencies: The function is unavailable (grayed out) and Off when:
• Gate Method is LO or Video and FFT Sweep Type is manually selected.
• Gate Method is FFT and Swept Sweep Type is manually selected.
• Marker Count is ON.
The following are unavailable whenever Gate is on:
• FFT under Sweep Type when Method=LO or Video or Swept under
Sweep Type when Method=FFT
•
Marker Count
While Gate is on, the Auto Rules for Sweep Type are modified so that the
choice agrees with the Gate Method: i.e., FFT for Method = FFT and Swept
for Method = LO or Video.
The Gate softkey and all SCPI under the [:SENSe]:SWEep:EGATe SCPI node
are grayed out when Source Mode is Tracking with an external source. This
is because the Gate circuitry is used to sync the external source. If the
Tracking Source is turned on, the Gate is turned off.
When in the ACP measurement:
• When Meas Method is RBW or FAST, this function is unavailable and the
key is grayed out.
• Whenever Gate is on, Meas Method, RBW or FAST is unavailable and
keys for those are grayed out.
• When Gate is on, Offset Res BW and Offset Video BW are ignored (if you
set these values) and the measurement works as if all Offset Res BW and
all Offset Video BW are coupled with the Res BW and the Video BW
under the BW menu. When Gate is on, the Offset BW key in the
Offset/Limit menu is grayed out.
Preset: Off
State Saved: Saved in instrument state
Range: On|Off
Backwards Compatibility SCPI: [:SENSe]:SWEep:TIME:GATE[:STATe] ESA compatibility
