Trigger
Reset Offset Display
Resets the value of the periodic trigger offset display setting to 0.0 seconds. The current displayed trigger
location may include an offset value defined with the
Offset key. Pressing this key redefines the
currently displayed trigger location as the new trigger point that is 0.0 s offset. The
Offset key can then
be used to add offset relative to this new timing.
Sync Source
Selects a signal source for you to synchronize your periodic timer trigger to, otherwise you are triggering
at some arbitrary location in the frame. Synchronization reduces the precision requirements on the
setting of the period.
For convenience you may adjust the level and slope of the selected sync source in a conditional branch
setup menu accessed from the Sync Source menu. Note that these settings match those in the Trigger
and Gate Source menus; that is, each trigger source has only one value of level and slope, regardless of
which menu it is accessed from.
Notes: The front panel interface (for example, the knob) and the :TRIG:FRAM:OFFS
command adjust the accumulated offset, which is shown on the active
function display. However, the actual amount sent to the hardware is the delta
value, that is, the current offset value minus the previous offset value.
When the SCPI command is sent the value shown on the key (and the Active
Function, if this happens to be the active function) is updated by increasing it
(or decreasing it if the value sent is negative) by the amount specified in the
SCPI command.
This is a "command only" SCPI command, with no query.
Dependencies: The invalid data indicator turns on when the offset is changed, until the next
sweep/measurement completes.
Couplings: The same offset is used in the Gate Source selection of the period timer.
Preset: 0 s
State Saved: Saved in instrument state
Min: –10.000 s
Max: 10.000 s
Default Unit: S
Initial S/W Revision: Prior to A.02.00
Key Path:
Trigger, Periodic Timer
Remote Command: :TRIGger[:SEQuence]:FRAMe:OFFSet:DISPlay:RESet
Example: TRIG:FRAM:OFFS:DISP:RES
Initial S/W Revision: Prior to A.02.00
Key Path:
Trigger, Periodic Timer
