1203
Source (Internal)
Clear Waveform from Slot
Allows you to clear the waveform from the selected slot.
Lock Waveform in Slot
If the selected slot is in the trial state or the lock required state, the waveform that occupies the slot is locked and
permanently licensed.
Initial S/W Revision: Prior to A.09.00
Key Path:
Source, Modulation Setup, ARB, Waveform Utilities, Multi-Pack Licenses
Remote Command: :SYSTem:LKEY:WAVeform:CLEar <int>
or
:SYSTem:LICense[:FPACk]:WAVeform:CLEar <int>
Example: SYST:LKEY:WAV:CLE 1
or
:SYST:LIC:WAV:CLE 1
Notes: The second SCPI :SYSTem:LICense[:FPACk]:WAVeform:CLEar is provided
to be consistent with the style of Agilent signal sources. You can use either
one of them.
Waveform slot number <int> is positive. If you attmpt to input a slot number
less than or equals 0, an error is generated. "-220 Parameter error; License slot
<n> is illegal, slot number must be positive"
Dependencies: This key is only available if the currently selected slot is in the trial state.
Initial S/W Revision: A.05.00
Key Path:
Source, Modulation Setup, ARB, Waveform Utilities, Multi-Pack Licenses
Remote Command: :SYSTem:LKEY:WAVeform:LOCK <int>
or
:SYSTem:LICense[:FPACk]:WAVeform:LOCK <int>
Example: SYST:LKEY:WAV:LOCK 1
or
SYST:LIC:WAV:LOCK 1
Notes: The second SCPI :SYSTem:LICense[:FPACk]:WAVeform:LOCK is provided
to be consistent with the style of Agilent signal sources. You can use either
one of them.
Waveform slot number <int> is positive. If you attmpt to input a slot number
less than or equals 0, an error is generated. "-220 Parameter error; License slot
<n> is illegal, slot number must be positive"
