128
About the Test Set
How the Test Set Is Used
E6607C
For any sequence that the test set runs using the MPA RFIO or GPS OUT ports, a single MPA RFIO port
must be designated the input port. For the output signal to the DUT, any of the MPA RFIO ports can be
designated as output ports. Up to eight of the MPA RFIO ports can provide an output signal at one time.
(However, if the MPA RFIO ports are used in input/output pairs, this will limit the number of available
output ports to four.) These port assignments cannot be changed during a sequence. The rules for port
assignments are:
• Only one port at a time can be the input port, and it must be one of the following: Rx/UL RF IN or
any one of MPA RFIO 0-7.
• MPA RFIO 0-7 serve as both input ports or output ports when the MPA RF OUT is connected to the
MPA IN.
• GPS 0-3 serve as output ports simultaneously when the GPS OUT is connected to the Dist .
Software Elements of the Test Set
The test set firmware, which runs within the Windows XP Pro operating system, controls the source and
analyzer, and provides access to a variety of licensed measurement applications which are available to be
installed on the test set.
The basic test set includes licenses for two applications: the IQ Analyzer Mode (U9060A) and the
Sequence Analyzer Mode (U9065A). Several other applications are available for installation. Many of
the measurements which are included in these applications can be run from within the Sequence
Analyzer mode, and not just in the native mode of the measurement. The table below shows all the
available applications, and the measurements they include. Measurements which can be run from within
the Sequence Analyzer mode are marked “available to sequencer” in the table.
Table 2-1 Applications and Measurements in the Test Set
Application Measurement
IQ Analyzer Mode
(U9060A)
• IQ Waveform
• Complex Spectrum
Analog Demodulation
Mode (U9063A)
• Amplitude Modulation
• Frequency Modulation
• Phase Modulation
Sequence Analyzer
Mode (U9065A)
• Basic measurements: Power, Phase & Frequency, Discrete PAvT, IQ Data
• List Sequencer
• All application-specific measurements listed below that are marked “available to
sequencer”.
