Meas Setup
Limit Fail? (Remote Command Only, SCPI standard Compatibility)
Tests a limit line against its associated trace. Returns a 0 if the trace is within the limit and margin, a 1 if
the trace exceeds either the limit or the margin. This command is identical to “:CALC:LLIN:FAIL?”
Note that this command only tests one limit line – other limit lines are not tested when executing this
command. To see whether a trace passed all limits, use :CALCulate:TRACe:FAIL?.
Note this command performs the test regardless of whether the trace or the limit is turned on on the
display.
State Saved: Saved in instrument state.
Initial S/W Revision: A.02.00
Remote Command: :CALCulate:LIMit[1]|2|3|4|5|6:UPPer:POINts?
Example: :CALC:LIM:UPP:POIN? returns the number of points in the upper limit line.
Preset: Upper Limit line data/points is cleared by Restore Mode Defaults.
State Saved: Saved in instrument state.
Initial S/W Revision: A.02.00
Remote Command: :CALCulate:LIMit[1]|2|3|4|5|6:LOWer[:DATA] <ampl>, …
:CALCulate:LIMit[1]|2|3|4|5|6:LOWer[:DATA]?
Example: :CALC:LIM:LOW –10, –10, –20, –20
describes the amplitude values of an lower limit line
Preset: Limit line data is cleared by Restore Mode Defaults.
State Saved: Saved in instrument state.
Initial S/W Revision: A.02.00
Remote Command: :CALCulate:LIMit[1]|2|3|4|5|6:LOWer:POINts?
Example: :CALC:LIM:UPP:POIN? returns the number of points in the lower limit line.
Preset: Limit line data/points is cleared by Restore Mode Defaults.
State Saved: Saved in instrument state.
Initial S/W Revision: A.02.00
Remote Command: :CALCulate:LIMit[1]|2|3|4|5|6:FAIL?
Example: :CALC:LIM:FAIL? returns a zero if limit line 1’s associated trace has no
failure, 1 if there is a margin or limit failure.
Couplings: This command is identical to :CALC:LLIN:FAIL?
Initial S/W Revision: A.02.00
