Code Domain
Meas Setup
settings affect sensitivity and IF overloads.
IF Gain Auto
Activates the auto rules for IF Gain.
IF Gain State
Selects the range of IF gain between Low Gain and High Gain.
Key Path Meas Setup, Advanced
Mode cdma2000
Remote Command [:SENSe]:CDPower:IF:GAIN:AUTO[:STATe] OFF|ON|0|1
[:SENSe]:CDPower:IF:GAIN:AUTO[:STATe]?
Example CDP:IF:GAIN:AUTO ON
CDP:IF:GAIN:AUTO?
Dependencies/Couplings When either the auto attenuation works (for example, with electrical attenuator), or
the optimize mechanical attenuator range is requested, the IF Gain setting is changed
as following rule.
‘auto’ sets IF Gain ‘High Gain’ under any of the following conditions: the input
attenuator is set to 0 dB, the preamp is turned on, or the Max Mixer Level is 20 dBm
or lower. For other settings, auto sets IF Gain to ‘Low Gain’.
Preset OFF
State Saved Saved in instrument state.
Range Off|On
Key Path
Meas Setup, Advanced, IF Gain
Mode cdma2000
Remote Command [:SENSe]:CDPower:IF:GAIN[:STATe] ON|OFF|1|0
[:SENSe]:CDPower:IF:GAIN[:STATe]?
Example CDP:IF:GAIN ON
CDP:IF:GAIN?
Dependencies/Couplings When either the auto attenuation works (for example, with electrical attenuator), or
the optimize mechanical attenuator range is requested, the IF Gain setting is changed
as following rule.
‘auto’ sets IF Gain ‘High Gain’ under any of the following conditions: the input
attenuator is set to 0 dB, the preamp is turned on, or the Max Mixer Level is 20 dBm
or lower. For other settings, auto sets IF Gain to ‘Low Gain’.
Remote Command Notes Where ON = high gain
OFF = low gain
