641
Occupied Bandwidth Measurement
Trace/Detector
Detector
Accesses a menu of functions that enables you to control the detectors for the current measurement. The
following choices are available:
• Auto- the detector selected depends on marker functions, trace functions, average type, and the trace
averaging function.
• Normal-the detector determines the peak of the CW-like signals, and it yields alternating maximums
and minimums of noise-like signals. This is also referred to as Rosenfell detection.
• Average-the detector determines the average of the signal within the sweep points. The averaging
method depends upon the Average Type selection (voltage, power or log scales).
• Peak (Positive)-the detector determines the maximum of the signal within the sweep points.
• Sample-the detector indicates the instantaneous level of the signal at the center of the sweep points
represented by each display point.
• Negative Peak-the detector determines the minimum of the signal within the sweep points.
Detector Selection
Allows you to select a specific detector for the current measurement. When the detector choice is Auto,
the analyzer selects the detector. The selected detector depends on marker functions, trace functions, and
trace averaging functions for the current measurement.
Key Path: Detector
Initial S/W Revision: Prior to A.02.00
Key Path:
Trace/Detector
Mode: WCDMA, C2K, WIMAX OFDMA, TD-SCDMA, 1xEVDO, LTE, LTETDD,
BLUETOOTH, WLAN
Remote Command: [:SENSe]:OBWidth:DETector[:FUNCtion]
NORMal|AVERage|POSitive|SAMPle|NEGative
[:SENSe]:OBWidth:DETector[:FUNCtion]?
Example: OBW:DET NORM
OBW:DET?
