677
Code Domain
Marker
Marker X Axis Value (Remote Command only)
Sets the marker X Axis value in the current marker X Axis Scale unit. It has no effect if the control mode
is
Off, but is the SCPI equivalent of entering an X value if the control mode is Normal or Delta.
NOTE This command is not valid when Marker Trace is ‘POLar’ (I/Q symbol polar
vector) and ignored. For Marker Trace ‘POLar’ (I/Q symbol polar vector), Marker
Symbol Value is supported instead.
Marker X Axis Position (Remote Command only)
Sets the marker X position in trace points. It has no effect if the control mode is Off, but is the SCPI
equivalent of entering a value if the control mode is
Normal or Delta - except in trace points rather than
X Axis Scale units. The entered value is immediately translated into the current X Axis Scale units for
setting the value of the marker.
Mode cdma2000
Remote Command :CALCulate:CDPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|1
2:X <real>
:CALCulate:CDPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|1
2:X?
Example CALC:CDP:MARK3:X 0.0
CALC:CDP:MARK3:X?
Restriction and Notes If no suffix is sent it uses the fundamental units for the current marker X
Axis Scale. If a suffix is sent that does not match the current marker X
Axis Scale unit, an error “Invalid suffix” is generated.
The query returns the marker’s absolute X Axis value if the control mode
is
Normal, or the offset from the marker’s reference marker if the control
mode is
Delta. The query is returned in the fundamental units for the
current marker X Axis scale: Hz for
Frequency and Inverse Time,
seconds for
Period and Time. If the marker is Off the response is not a
number.
Preset After a preset, all Markers are turned OFF, so Marker X Axis Value
query does not return a number (NAN).
State Saved No
Min ñ9.9E+37
Max 9.9E+37
Mode cdma2000
