1223
Source (Internal)
Free Run
Sets the trigger input for the current step to Free Run.
Internal
Sets the trigger input for the current step to Internal.
Manual (Trigger Key)
Sets the trigger input for the current step to Manual (Trigger Key). Any step in the sequence set to Manual will
cause the sequence execution to stop until the manual trigger key is pressed. Sending the Bus Trigger SCPI
command will have no effect. At any point in the sequence where the list sequencer is paused waiting for a
software trigger, a pop up dialog is displayed until the trigger event occurs.
Bus
Sets the trigger input for the current step to Bus. Any step in the sequence set to Bus will cause the sequence
execution to stop until the Bus Trigger SCPI command is sent. Pressing the manual trigger key has no effect. At
any point in the sequence where the list sequencer is paused waiting for a software trigger, a pop up dialog is
displayed until the trigger event occurs.
Key Path:
Source, List Sequencer, List Sequencer Setup, Step Trigger
Example: SOUR:LIST:STEP2:SET:INP:TRIG IMM
Notes: SCPI is supported after A.09.40
Initial S/W Revision: A.05.00
Key Path:
Source, List Sequencer, List Sequencer Setup, Step Trigger
Example: SOUR:LIST:STEP2:SET:INP:TRIG INT
Notes: SCPI is supported after A.09.40
Initial S/W Revision: A.05.00
Key Path:
Source, List Sequencer, List Sequencer Setup, Step Trigger
Example: SOUR:LIST:STEP2:SET:INP:TRIG KEY
Notes: SCPI is supported after A.09.40
Initial S/W Revision: A.05.00
Key Path:
Source, List Sequencer, List Sequencer Setup, Step Trigger
Example: SOUR:LIST:STEP2:SET:INP:TRIG BUS
Notes: SCPI is supported after A.09.40
Initial S/W Revision: A.05.00
