AMPTD Y Scale
measurement, Swept SA, does not support this functionality.
Mech + Elec Atten
In dual attenuator models, this selects both attenuators participate in the autoranging.
This key is grayed out in measurements that do not support this functionality. The spectrum analyzer
measurement, Swept SA, does not support this functionality.
(Mech) Atten Step
This controls thestep size used when making adjustments to the input attenuation.
This key is labeled
Mech Atten Step in dual attenuator models and Atten Step in single attenuator
models. In the dual attenuator configuration, this key only affects the step size of the mechanical
attenuator.
Key Path: AMPTD Y Scale, Attenuation, Pre-Adjust for Min Clip
Example: :POW:RANGe:OPT:ATT ELEC
Initial S/W Revision: Prior to A.02.00
Key Path:
AMPTD Y Scale, Attenuation, Pre-Adjust for Min Clip
Example: :POW:RANGe:OPT:ATT COMB
Initial S/W Revision: Prior to A.02.00
Key Path:
AMPTD Y Scale, Attenuation
Remote Command: [:SENSe]:POWer[:RF]:ATTenuation:STEP[:INCRement] 10 dB |
2 dB
[:SENSe]:POWer[:RF]:ATTenuation:STEP[:INCRement]?
Example: POW:ATT:STEP 2
Notes: Note this feature works like a 1-N choice from the front panel, but it takes a
specific value (in dB) when used remotely. The only valid values are 2 and 10.
Dependencies: Blanked in CXA and EXA if option FSA (2 dB steps) is not present. If
blanked, attempts to set it via SCPI will yield an error.
Couplings: When the attenuation step size changes, the current mechanical attenuation
value is adjusted (if necessary) to be quantized to the new step size. That is, if
step is set to 10 dB, mech atten is increased if necessary so it is a multiple of
10 dB
Preset: PXA and MXA: 2 dB
EXA and CXA: 10 dB (2 dB with option FSA)
EXT: 2 dB
State Saved: Saved in instrument state
