1020
Marker Function
Window
This key turns the Measure at Marker window on and off. It turns on automatically when Measure at
Marker is initiated and turns off on a Preset. If the Window is turned on without a Measure at Marker
result, --- is displayed for each result for which the detector is not “Off”.
Position
This key controls the placement of the Measure at Marker window on the display.
Detectors
This key opens up a menu that allows you to configure the detectors to be used for the Measure at
Marker reading. Any of the test set detectors can be used for each of the three detectors, or any of the
three can be turned off. The dwell time for each detector is also settable.
When performing a Meas at Marker, the dwell time settings that you select will depend on the
characteristics of the emission you are measuring. The default dwell time (200 ms) should work well for
Readback In square brackets, the state of the window then the window position,
separated by commas, as [On, Left]
Initial S/W Revision A.02.00
Key Path
Marker Function, Measure at Marker, Meas at Marker Window
Remote Command :DISPlay:WINDow:MAMarker[:STATe] ON|OFF|1|0
:DISPlay:WINDow:MAMarker[:STATe]?
Example :DISP:WIND:MAM ON
Couplings The window turns on automatically when Measure at Marker is initiated and
turns off on a Preset.
Preset Off
State Saved Saved in instrument state
Readback Text On|Off
Initial S/W Revision A.02.00
Key Path
Marker Function, Measure at Marker, Meas at Marker Window
Remote Command :DISPlay:WINDow:MAMarker:POSition LEFT|RIGHt
:DISPlay:WINDow:MAMarker:POSition?
Example :DISP:WIND:MAM:POS RIGH
Preset Right
State Saved Saved in instrument state
Readback Text Left|Right
Initial S/W Revision A.02.00
