1242
Source (Internal)
Power
Allows you to specify a power value for the current step.
Waveform
Allows you access to the sub-menus for selecting the waveform to be played back during the current
step. Pressing this key also changes the central display area to show the Waveform File Selection view.
Key Path: Source, List Sequencer, List Sequencer Setup
Remote Command: :SOURce:LIST:STEP[1]|2|3…1000:SETup:AMPLitude <double>
:SOURce:LIST:STEP[1]|2|3…1000:SETup:AMPLitude?
Example: SOUR:LIST:STEP2:SET:AMPL –50dBm
SOUR:LIST:STEP2:SET:AMPL?
Notes: SCPI is supported after A.09.40
Notes: Amplitude corrections can be specified for use with the source. In the event of
amplitude corrections being applied, the valid ranges for the RF power do not
change dependant on the current amplitude correction setting. Instead, if the
combination of RF power + amplitude correction is higher or lower than the
source output range, the Source Unleveled bit is set and the “Source
Unleveled” indicator will appear on status panel to indicate that the source
cannot maintain the output power that has been requested.
Notes: The Min and Max value here defined UI settable amplitude range. This range
is larger than actual amplitude range with level accuracy defined in spec.
Dependencies: The RF power is dependent on the RF output port and frequency, such that the
current frequency and selected output port determine the valid range of power
values.
Preset: –100 dBm
Min: The range of values depends on the current frequency and selected RF output
port. Please refer to “RF Power” on page 1138 and the table RF Power Range
for the valid ranges.
Max: The range of values depends on the current frequency and selected RF output
port. Please refer to “RF Power” on page 1138 and the table RF Power Range
for the valid ranges.
Initial S/W Revision: A.05.00
Key Path:
Source, List Sequencer, List Sequencer Setup
Remote Command: :SOURce:LIST:STEP[1]|2|3…1000:SETup:WAVeform <string>
:SOURce:LIST:STEP[1]|2|3…1000:SETup:WAVeform?
Example: SOUR:LIST:STEP2:SET:WAV “CW”
SOUR:LIST:STEP2:SET:WAV?
Notes: SCPI is supported after A.09.40
