Spectrum Emission Mask Measurement
Meas Setup
Meas BW
Allows you to specify a multiplier of Res BW for the measurement integration bandwidth.
Meas BW is multiplier integer number. It shows a ratio between Integration BW and Resolution BW of
the measurement result.
Integ BW = Meas BW * Resolution BW
Integration BW is desired resolution bandwidth and Resolution BW is actual bandwidth for sweep.
Measurement sweeps with Resolution BW and Meas BW compensates sweep resolution bandwidth to
Integration BW.
If you set this parameter greater than 1, you can set Resolution BW narrower to avoid carrier power
Preset: For modes (except WLAN), the preset value is as follows.
WCDMA: 30.00 kHz, 30.00 kHz, 30.00 kHz, 100.00 kHz, 1.000 MHz,
1.00 MHz|30.00 kHz, 1.000 MHz, 1.000 MHz, 1.000 MHz, 1.000 MHz, 1.00
MHz
C2K: 3.00 kHz, 30.00 kHz, 30.00 kHz, 6.2 kHz, 1.000 MHz, 1.00 MHz|30.00
kHz, 30.00 kHz, 6.2 kHz, 1.000 MHz, 1.000 MHz, 1.00 MHz
WIMAX OFDMA: 100 KHz, 100 KHz, 100 KHz, 100 KHz, 100 KHz,
100 KHz| 100 KHz, 100 KHz, 100 KHz, 100 KHz, 100 KHz, 100 KHz
TD-SCDMA: 30 kHz, 30 kHz, 30 kHz, 50 kHz, 1 MHz, 1 MHz| 30 kHz,
30 kHz, 50 kHz, 1 MHz, 1 MHz, 1 MHz
1xEVDO: 30.00 kHz, 30.00 kHz, 30.00 kHz, 6.2 kHz, 1.000 MHz, 1.000
MHz|30.00 kHz, 30.00 kHz, 30.00 kHz, 30.00 kHz, 30.00 kHz, 30.00 kHz
LTE, LTETDD: 51 kHz, 100 kHz, 1.0 MHz, 1.0 MHz,1.0 MHz, 1.0 MHz|15.0
kHz, 510 kHz,1.0 MHz,1.0 MHz,1.0 MHz,1.0 MHz
---------------
WLAN: 100 KHz, 100 KHz, 100 KHz, 100 KHz, 100 KHz, 100 KHz,
100 KHz, 100 KHz, 100 KHz, 100 KHz, 100 KHz, 100 KHz
Modes (except WLAN): OFF, OFF, OFF, OFF, OFF, OFF|OFF, OFF, OFF,
OFF, OFF, OFF
WLAN: OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF
|OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF
State Saved: Saved in instrument state.
Min: 1 Hz
Max: 8 MHz
Backwards Compatibility SCPI: [:SENSe]:SEMask:OFFSet[1]|2:LIST:BWIDth[:RESolution]
Initial S/W Revision: Prior to A.02.00
Modified at S/W Revision: A.02.00, A.03.00, A.10.00, A.11.00
