Input/Output
correct it before displaying it. By definition all points are connected. If a gap is desired for corrections data, enter
0 dB.
Note that a well-designed Corrections array should start at 0 dB and end at 0 dB. This is because whatever the high
end point is will be extended to the top frequency of the instrument, and whatever the low end point is will be
extended down to 0 Hz. So for a Corrections array to have no effect outside its range, you should start and end the
array at 0 dB.
NOTE The table editor will only operate properly if the analyzer is sweeping, because its updates
are tied to the sweep system. Thus, you should not try to use the editor in single sweep,
and it will be sluggish during compute-intensive operations like narrow-span FFT sweeps.
When exiting the edit menu (by using the
Return key or by pressing an instrument front-panel key), the editor
window turns off and the Ampcor trace is no longer displayed; however,
Apply Corrections remains On, any
correction that was on while in the editor remains on, and the amplitude scale returns to its previous setting.
Corrections arrays are not affected by a Preset, because they are in the Input/Output system. They also survive
shutdown and restarting of the analyzer application, which means they will survive a power cycle.
When editing a correction, the editor remembers which correction and which element in the correction array you
were editing, and returns you to that correction and that element when you return to the editor after leaving it.
Navigate
Lets you move through the table to edit the desired point.
Frequency
Lets you edit the frequency of the current row.
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections
Initial S/W Revision: A.10.00
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Edit
Notes: There is no value readback on the key
Min: 1
Max: 2000
Initial S/W Revision: A.10.00
Key Path:
Input/Output, RF Output & Test Set Config, Multiport Adapter,
Corrections, Edit
Notes: There is no value readback on the key.
Min: 0
Max: 1 THz
