Source (Internal)
Pressing this key changes the central view area to show the Waveform File Selection view.
Select Waveform
Allows you to select a waveform sequence or segment for the dual ARB to play.
Segments on Hard Disk
Allows you access to the sub-menus for loading waveform segments from the hard disk into ARB memory. The
default directory is: D:\nvarb.
Key Path:
Source, Modulation Setup, ARB
Initial S/W Revision: A.05.00
Key Path:
Source, Modulation Setup, ARB, Select Waveform
Remote Command: :SOURce:RADio:ARB:WAVeform <string>
:SOURce:RADio:ARB:WAVeform?
Example: SOUR:RAD:ARB:WAV “test_waveform.bin”
Notes: <string> - specifies the name of the waveform segment or waveform sequence
to be played by the ARB.
When in Sequence Analyzer mode, and Include Source is Yes, if the you
attempt to play a waveform sequence but not all the required waveform
segments are in the ARB playback memory, the application will reject the
loading operation with an error is generated .
When Include Source is No, if you attempt to play a waveform sequence but
not all the required waveform segments are contained in the ARB playback
memory, the application will attempt to load the required segments from either
the default directory of the current directory. If the ARB memory does not
have enough space for all the waveform segments to be loaded, an error is
generated and none of the waveform segments is loaded.
If the ARB is ON, and you attampt to play a waveform sequence but not all
the waveform segments within the sequence could be found to be loaded into
ARB memory, an error is generated. The selected waveform keeps the
previous value and ARB state remains On.
If you specify a waveform segment over SCPI but the waveform segment is
not present within ARB playback memory and cannot be found for auto
loading within the current directory or the default directory, an error is
generatedand the file selection remains unchanged.
If you select a waveform for playback and the waveform requires a license
that is not installed on the instrument, an error is generated.error is generated.
If the ARB is ON and you load a file to ARB memory or delete a file from
ARB memory, the playing waveform segment may not keep phase continuity
during the ARB memory operation. The waveform will be replayed after the
ARB operation is finished.
Initial S/W Revision: A.05.00
