Source (Internal)
List Sequencer Setup
Allows you access to the list sequencer setup menus.
Number of Steps
Allows you to specify the number of steps within the list sequence.
Current Step
Allows you to select the step number you wish to view or edit.
Insert Step Before
Allows you to insert a new step, containing default values, before the currently selected step. Inserting a
step will automatically increase the Step Count parameter by 1. If sequence already reaches upper limit
of 1000 steps, then insert more step will be rejected and popup error –221, “Setting Conflict; Cannot
Key Path: Source, List Sequencer
Key Path: Source, List Sequencer, List Sequencer Setup
Remote Command: :SOURce:LIST:NUMBer:STEPs <integer>
:SOURce:LIST:NUMBer:STEPs?
Example: SOUR:LIST:NUMB:STEP 1
Notes: Increasing the number of steps creates additional steps at the end of the list,
with all the settings within the steps set to their default values.
Decreasing the number of steps removes steps from the end of the list. The
settings within the removed steps are not reset. This means that increasing the
number of steps again would allow you to retrieve these steps.
Dependencies: The Step Count parameter is increased or decreased when you insert or delete
a point from within the GUI interface to the sequencer.
Preset: 1
Min: 1
Max: 1000
Initial S/W Revision: A.05.00
Key Path:
Source, List Sequencer, List Sequencer Setup
Notes: No remote command, front panel only.
Preset: 1
Min: 1
Max: Step Count
Initial S/W Revision: A.05.00
