View/Display
Screen
This controls the display of the annunciation and annotation around the graticule, including any
annotation on lines (such as the display line, the threshold line, etc.) and the y-axis annotation. This does
NOT include marker annotation (or the N dB result). When off, the graticule expands to fill the entire
graticule area, leaving only the 1.5% gap above the graticule as described in the Trace/Detector chapter.
Trace
Turns on and off the labels on the traces, showing their detector (or their math mode) as described in the
Trace/Detector section.
If trace math is being performed with a trace, then the trace math annotation will replace the detector
annotation.
Preset: On
This should remain Off through a Preset when
System Display Settings,
Annotation is set to Off.
State Saved: Saved in instrument state.
Initial S/W Revision: Prior to A.02.00
Key Path:
View/Display, Display, Annotation
Remote Command: :DISPlay:ANNotation:SCReen[:STATe] OFF|ON|0|1
:DISPlay:ANNotation:SCReen[:STATe]?
Example: DISP:ANN:SCR OFF
Dependencies: Grayed-out and forced to OFF when
System Display Settings, Annotation is
set to Off.
Preset: On
This should remain Off through a Preset when
System Display Settings,
Annotation is set to Off
State Saved: Saved in instrument state.
Initial S/W Revision: Prior to A.02.00
Key Path:
View/Display, Display, Annotation
Remote Command: :DISPlay:ANNotation:TRACe[:STATe] ON|OFF|1|0
:DISPlay:ANNotation:TRACe[:STATe]?
Example: DISP:ANN:TRAC OFF
Preset: Off
State Saved: Saved in instrument state.
Initial S/W Revision: Prior to A.02.00
