LTE FDD Channel Number Ranges
The carrier frequency in the uplink and downlink is designated by the E-UTRA Absolute Radio
Frequency Channel Number (EARFCN) in the range 0 – 65535. The relation between EARFCN and the
carrier frequency in MHz for the downlink is given by the following equation, where F
DL_low
and
N
Offs-DL
are given in table 5.4.4–1 and N
DL
is the downlink EARFCN.
F
DL
= F
DL_low
+ 0.1(N
DL
– N
Offs-DL
)
The relation between EARFCN and the carrier frequency in MHz for the uplink is given by the following
equation where F
UL_low
and N
Offs-UL
are given in table 5.4.4–1 and N
UL
is the uplink EARFCN.
F
UL
= F
UL_low
+ 0.1(N
U
L – N
Offs-UL
)
400 Euro PAMR Uplink (MS,
reverse link)
Uplink (MS,
reverse link)
Uplink (MS,
reverse link)
1 ≤ N ≤ 400
472 ≤ N ≤ 871
1536 ≤ N ≤ 1715
0.025×(N–1)+ 450.000
0.025×(N–472)+ 410.000
0.025×(N–1536)+ 479.000
Downlink (BS,
forward link)
Downlink (BS,
forward link)
Downlink (BS,
forward link)
1 ≤ N ≤ 400
472 ≤ N ≤ 871
1536 ≤ N ≤ 1715
0.025×(N–1)+ 460.000
0.025×(N–472)+ 420.000
0.025×(N–1536)+ 489.000
800 PAMR Uplink (MS,
reverse link)
0 ≤ N ≤ 239 870.0125 + 0.025×N
Downlink (BS,
forward link)
0 ≤ N ≤ 239 915.0125 + 0.025×N
Band Downlink Uplink
F
DL_low
(MHz)
N
Offs-DL
Range of N
DL
F
UL_low
(MHz) N
Offs-UL
Range of N
UL
1 2110 0 0 – 599 1920 18000 18000 – 18599
2 1930 600 600 - 1199 1850 18600 18600 – 19199
3 1805 1200 1200 – 1949 1710 19200 19200 – 19949
4 2110 1950 1950 – 2399 1710 19950 19950 – 20399
5 869 2400 2400 – 2649 824 20400 20400 – 20649
6 875 2650 2650 – 2749 830 20650 20650 – 20749
Band Link (Device) Range Frequency (MHz)
