678
Code Domain
Marker
Marker Y Axis Value (Remote Command only)
Queries the marker Y Axis value in the current marker Y Axis unit.
Marker Select
Displays 12 markers available for selection.
Marker Type
Sets the marker control mode. If the selected marker is Off, pressing Marker sets it to Normal and places
it at the center of the screen on the trace determined by the
Marker Trace rules. At the same time,
Remote Command :CALCulate:CDPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|1
2:X:POSition <real>
:CALCulate:CDPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|1
2:X:POSition?
Example CALC:CDP:MARK10:X:POS 0.0
CALC:CDP:MARK10:X:POS?
Restriction and Notes The query returns the marker’s absolute X Axis value in trace points if
the control mode is
Normal, or the offset from the marker’s reference
marker in trace points if the control mode is
Delta. The value is returned
as a real number, not an integer, corresponding to the translation from X
Axis Scale units to trace points (see “Fractional Trace Points”, above). If
the marker is
Off the response is not a number.
The description provided in the MIN/MAX/DEF Support field is only for
the SCPI tester. The remote command supports all the MIN/MAX/DEF
parameters.
Preset After a preset, all Markers are turned OFF, so Marker X Axis Value
query does not return a number (NAN).
State Saved No
Min ñ9.9E+37
Max 9.9E+37
Mode cdma2000
Remote Command :CALCulate:CDPower:MARKer[1]|2|3|4|5|6|7|8|9|10|11|1
2:Y?
Example CALC:CDP:MARK11:Y?
Preset Result dependant on markers setup and signal source
State Saved No
Key Path
Marker
