212
System Functions
Save
instruments frequency range.
Analyzer Sequence
Only Available in: Sequence Analyzer Mode
The list of parameters, that configure steps, that makes up a sequence for the Analyzer.
The Analyzer sequence is a sequence of flexible configurable steps that can be set anywhere in the
instruments frequency range for measuring the performance of a transmitters output
Source and Analyzer Sequence
Available in: Sequence Analyzer Mode
The list of parameters, that configure steps, that makes up a sequence for the Analyzer and the Source.
The Source and Analyzer sequence is completely configurable and can have internal triggers between
the source and the analyzer to orchestrate a sequence to completely test an external transmitter and
receiver’s performance.
Save As . . .
This menu lets you select the location where you can save the Sequence. This menu is a standard
Windows® dialog with Save As menu keys. The "File Name" field in the Save As dialog is initially
loaded with an automatically generated filename specific to the appropriate Save Type. The
automatically generated filename is guaranteed not to conflict with any filename currently in the
directory. You may replace or modify this filename using the File Name softkey. See the Quick Save key
documentation for more on the automatic file naming algorithm.
The default path for all Sequence Files is:
Key Path: Save, Sequences
Example: :MMEM:STOR:SEQ:SLIS "MySequence.txt"
Dependencies: Only available in XOBT
Initial S/W Revision: A.05.00
Key Path:
Save, Sequences
Example: :MMEM:STOR:SEQ:ALISt "MySequence.txt"
Dependencies: Only available in XOBT, Sequence Analyzer mode
Initial S/W Revision: A.05.00
Key Path:
Save, Sequences
Example: :MMEM:STOR:SEQ:SAAL "MySequence.txt"
Dependencies: Only available in XOBT, Sequence Analyzer mode
Initial S/W Revision: A.05.00
