Mode
Clear out all preloads and close and restart the test set program with only the requested application
preloaded, and with that application running. This choice is guaranteed to allow you to run the requested
application; but you will lose your previously configured preloads. In addition, there may be little or no
room for other applications, depending on the size of the requested application.
Bring up the Configure Applications utility in order to reconfigure the preloaded apps to make room for
the applications you want to run (this will then require restarting the test set program with your new
configuration). This is the recommended choice because it gives you full flexibility to select exactly
what you want.
Exit the dialog box without doing anything, which means you will be unable to load the application you
requested.
In each case except 4, this will cause the test set software to close, and you will lose all unsaved traces
and results.
If you attempt to load a mode via SCPI that will exceed memory capacity, the Mode does not load and an
error message is returned:
–225,"Out of memory;Insufficient resources to load Mode (mode name)"
where “mode name” is the SCPI parameter for the Mode in question, for example, BASIC for IQ
Analyzer Mode.
Application Mode Number Selection (Remote Command Only)
Select the measurement mode by its mode number. The actual available choices depend upon which
applications are installed in your instrument. The modes appear in this table in the same order they
appear in the Mode menu (if the order is not changed by the Configure Applications utility found in the
System, Power On menu). See “Detailed List of Modes” on page 1098 for Mode details.
The Mode Number is the parameter for use with the :INSTrument:NSELect command. The Mode
Parameter is the parameter for use with the :INSTrument[:SELect] command.
Mode Mode Number Mode Parameter
Sequence Analyzer 400 SEQAN
I/Q Analyzer (Basic) 8 BASIC
WCDMA with HSPA+ 9 WCDMA
GSM/EDGE/EDGE Evo 13 EDGEGSM
802.16 OFDMA
(WiMAX/WiBro)
75 WIMAXOFDMA
Analog Demod 234 ADEMOD
Bluetooth 228 BTooth
TD-SCDMA with HSPA/8PSK 211 TDSCDMA
cdma2000 10 CDMA2K
1xEV-DO 15 CDMA1XEV
