DĆ2 800 Series Operator's Manual
Connecting to a 270 COĆoximeter
Use this procedure to connect an 800 system to a 270 CO-oximeter.
Materials Required:
S 800 to 270 interface cable (part number 014117701)
To prevent electrical shock and damage to either system, disconnect
the 800 system and 270 CO-oximeter from the AC power source before installing
the cable. Refer to Shutting Down and Restarting the System in Section 5 for the
procedure to disconnect the 800 system.
1. Disconnect the 800 system from the AC power source.
2. Disconnect the 270 CO-oximeter from the AC power source.
3. Connect the 9-pin connecter of the interface cable to serial port 2 or 3 on the
800 system. Refer to Figure D-1.
4. Connect the 25-pin connector to port 1, 2, or 3 on the 270.
5. Tighten the hold down screws on the connectors.
6. Restore power to the 800 system and to the 270.
7. Refer to Configuring for External Devices in Section 5 to configure the 800
system for the 270.
8. Refer to Configuring a 270 CO-oximeter in Section 6 of the
270 CO-oximeter Operator’s Manual to configure the 270 for the 800 system.
9. Define the setup at the 270 CO-oximeter:
a. At the Main Menu, press the right arrow key two times, and press
SETUP.
b. Press the right arrow key two times, and press
INTERFACES.
c. Press PORT NO.
The port numbers 1, 2 and 3 correspond to the port labels on the 270 rear
panel.
d. Enter the number of the serial port to which the interface cable is
connected, and press
ENTER.
e. Press the right arrow key twice, and select LIS3.
