74 Model 2700 Transmitter with PROFIBUS-PA
Configuration
4.15 Configuring sensor parameters
The sensor parameters are used to describe the sensor component of your flowmeter. These sensor
parameters are not used in transmitter processing, and are not required:
• Serial number
• Sensor material
• Liner material
•Flange
To configure the sensor parameters, refer to the flowcharts in Figure 4-16.
Figure 4-16 Configuring sensor parameters
MMI Coriolis Flow >
Transducer Block >
Device Information
Sensor Serial Number
Sensor Material
Liner Material
Flange Type
Block: Transducer Block 2 (Slot 12)
Index 10 (sensor serial number)
Index 13 (sensor material)
Index 14 (liner material)
Index 15 (flange type)
Sensor parameters
Sensor tab
Enter the sensor serial
number in the
Sensor s/n
box
Apply
ProLink >
Configuration
Select the sensor serial
material from the Sensor
Matl list
Select the liner material
from the Liner Matl list
Select the flange from the
Flange list
EDD Bus parameters
ProLink II
