Configuration and Use Manual 67
Configuration
Startup ConfigurationCalibrationBefore You Begin Startup ConfigurationCalibrationBefore You Begin Startup ConfigurationCalibrationBefore You Begin Startup ConfigurationCalibrationBefore You Begin
To configure status alarm severity, refer to the flowcharts in Figure 4-11. Some configurable alarms
can be set to either Informational or Ignore, but not to Fault.
Figure 4-11 Configuring status alarm severity
A103 43 Data loss possible Informational Yes
A104 44 Calibration in progress Informational
(1)
Ye s
A105 45 Slug flow Informational Yes
A107 47 Power reset occurred Informational Yes
A116 56 API temperature outside standard range Informational Yes
A117 57 API density out of limits Informational Yes
A120 60 Concentration measurement: unable to
fit curve data
Informational No
A121 61 Concentration measurement: extrapolation alarm Informational Yes
A131 71 Smart Meter Verification in progress Informational Yes
A132 72 Simulation mode active Informational
(1)
Ye s
(1) Can be set to either Informational or Ignore, but cannot be set to Fault.
Table 4-12 Status alarms and severity levels (continued)
Alarm code Index
Description
Default
severity Configurable
Block: Transducer Block 1 (Slot 11)
Index 149 (Alarm index)
Select alarm
Block: Transducer Block 1 (Slot 11)
Index 150 (Alarm severity)
Set severity
EDD
Bus parameters
ProLink II
Alarm tab
Select an alarm from
the Alarm list
Apply
ProLink >
Configuration
Select a severity from
the Severity list
