Configuration and Use Manual 145
Slave Diagnostic Response Bytes
Status Bytes Block ParametersDiagnostic BytesProLink
Table E-11 Byte 11
Bit Indication
24 Reserved (always set to 0)
25 Reserved (always set to 0)
26 Reserved (always set to 0)—Not used
27 Reserved (always set to 0)
28 Reserved (always set to 0)
29 Reserved (always set to 0)
30 Reserved (always set to 0)
31 Reserved (always set to 0)
Table E-12 Byte 12
Bit Indication
32 Reserved
33 Reserved
34 Reserved
35 Restart (A107)
36 Cold start (A107)
37 Maintenance required—Not used
38 Reserved
39 Ident_Number violation
Table E-13 Byte 13
Bit Indication
40 Maintenance alarm (A014, A001, A002, A003, A022, A023, A024, A026)
41 Maintenance demanded (A103)
42 Function check (A106 if any function block is in simulation mode)
43 PRO_COND (not used)
44 Reserved (always set to 0)
45 Reserved (always set to 0)
46 Reserved (always set to 0)
47 Reserved (always set to 0)
