Configuration and Use Manual 167
Model 2700 PROFIBUS Block Parameters
Status Bytes Block ParametersDiagnostic BytesProLink
78= Not used
79= Not used
80= Not used
81= Not used
82= Not used
83= Not used
84= Not used
85= Not used
86= Not used
87= Not used
88= Not used
89= Not used
90= Not used
91= Not used
92= Not used
93= Not used
94= Not used
95= Not used
96= Not used
97= Not used
98= Not used
99= Not used
100= Not used
101= Not used
102= Not used
103= Not used
104= Not used
105-252 = Not used
253= Not used
254= Not used
255= Not used
231 UI_NumDecimals For Totals, the number of digits to
the right of the decimal point to
display on LDO
VARIABLE Unsigned8 1 S - R/W 0 to 5 R-1368
232 UI_ProcessVariables
(LDO_VAR_1_CODE)
(DD Name: Display Variable 1)
Display the Variable
#1associated with the code on
the LDO
ENUM Unsigned16 2 S 0 R/W 0 = Mass Flow Rate
1 = Temperature
2 = Mass Total
3 = Density
4 = Mass Inventory
5 = Volume Flow
Rate
6 = Volume Total
7 = Volume Inventory
8 – 11 = Not used
12= Not used
13= Not used
14= Not used
15 = API: Corr
Density
16 = API: Corr Vol
Flow
17 = API: Corr Vol
Tota l
18 = API: Corr Vol Inv
19 = API: Avg
Density
20 = API: Avg Temp
21 = CM: Density At
Ref
22 = CM: Density (
SGU)
23 = CM: Std Vol
Flow Rate
24 = CM: Std Vol
Tota l
25 = CM: Std Vol
Inventory
26 = CM: Net Mass
Flow
27 = CM: Net Mass
Tota l
28 = CM: Net Mass
Inv
29 = CM: Net Vol
Flow Rate
30 = CM: Net Vol
Tota l
31 = CM: Net Vol
Inventory
32 = CM:
Concentration
33 = API: CTL
34-45 = Not used
46 = Raw Tube
Frequency
47 = Drive Gain
48 = Case
Temperature
49 = LPO Amplitude
50 = RPO Amplitude
R-1117
Table F-5 Transducer block 1 parameters (continued)
Index Parameter Mnemonic Definition Message
Ty pe
Data Type/
Structure
Size Store
/Rate
(HZ)
Default
Value
Access Enumerated List of
Values / Range
Modbus
Register /
Coil
