4 Model 2700 Transmitter with PROFIBUS-PA
Before You Begin
1.7 Planning the configuration
Refer to the configuration overview flowchart in Figure 1-1 to plan transmitter configuration. In
general, perform configuration steps in the order shown here.
Note: Depending on your installation and application, some configuration tasks may be optional.
Note: This manual provides information on topics that are not included in the configuration overview
flowchart, e.g., using the transmitter, troubleshooting, and calibration procedures. Be sure to review
these topics as required.
Figure 1-1 Configuration overview
Chapter 2
Flowmeter Startup
Chapter 1
Before You Begin
Fill out pre-configuration
worksheet
Apply power
Set node address
Chapter 3
Calibration
OPTIONAL
Characterize the flowmeter
Zero the flowmeter
Verify meter performance
Validate against a standard
Calibrate for density
Calibrate for temperature
Chapter 4
Configuration
Configure AI function block
channels
Set I/O mode
Measurement units
Output scale
Process alarms
Damping
Slug flow
Alarm severity
Gas standard volume
Petroleum measurement
Concentration measurement
Cutoffs
Measurement mode
Device settings
Sensor parameters
Display functionality
Optional:
Configure pressure
compensation
Optional:
Configure temperature
compensation
