Configuration and Use Manual 157
Model 2700 PROFIBUS Block Parameters
Status Bytes Block ParametersDiagnostic BytesProLink
59 SNS_VolTotalUnits
(DD Name: Volume Total/Inv
Units)
Standard or special volume total
or mass inventory unit
ENUM Unsigned16 2 S l/s R 0000 = None
1034 = m3
1036 = cm3
1038 = l
1043 = ft3
1048 = gal
1049 = ImpGal
1051 = bbl
1641 = Beer bbl
R-0046
60 SNS_ResetMassInv
(DD Name: Reset Mass
Inventory)
Reset Mass Inventory (“On” =
Reset, “Off” = N/A)
METHOD Unsigned8 1 D - R/W 0X00 = None
0X01 = Reset
Coil – 0192
61 SNS_ResetVolInv
(DD Name: Reset Volume
Inventory)
Reset Volume Inventory (“On” =
Reset, “Off” = N/A)
METHOD Unsigned8 1 D - R/W 0x00 = None
0X01 = Reset
Coil – 0193
Gas Process Variables
62 SNS_EnableGSV
(DD Name: Enable Gas Std
Volume Flow And Total)
Enable/Disable Gas Standard
Volume Flow and Totals
ENUM Unsigned8 1 S 0x00 R/W 0x00 = disabled
0x01 = enabled
Coil-0078
63 SNS_GSV_GasDens
(DD Name: Gas Std Density)
Gas Density used to calculate
Reference Volume Gas Flow and
Tota ls
VARIABLE FLOAT 4 S 0.075
2
lb/ft3
R/W Density Sensor limits R-0453-
0454
64 SNS_GSV_VolFlow
(DD Name: Gas Std Volume
Flow Rate)
Reference Volume Gas Flow
Rate (not valid when API or ED is
enabled)
VARIABLE 101 5 D/20 0 R N/A R-0455-
0456
65 SNS_GSV_VolTot
(DD Name: GSV Total)
Reference Volume Gas Total (not
valid when API or ED is enabled)
VARIABLE 101 5 D/20 0 R N/A R-0457-
0458
66 SNS_GSV_VolInv
(DD Name: GSV Inventory)
Reference Volume Gas Invnetory
(not valid when API or ED is
enabled)
VARIABLE 101 5 D/20 0 R N/A R-0459-
0460
67 SNS_GSV_FlowUnits
(DD Name : GSV Flow Units)
Gas Standard Volume Flow
Engineering Units
ENUM Unsigned16 2 S SCFM R/W 1360 = SCFM
1361 = SCFH
1605 = SCFD
1522 = Nm3/s
1523 = Nm3/m
1524 = Nm3/h
1525 = Nm3/d
1527 = Sm3/s
1528 = Sm3/m
1529 = Sm3/h
1530 = Sm3/d
1532 = NL/s
1533 = NL/m
1534 = NL/h
1535 = NL/d
1537 = SL/s
1538 = SL/m
1539 = SL/h
1540 = SL/d
1604 = SCFS
R-2601
68 SNS_GSV_TotalUnits
(DD Name: GSV Total/Inv
Units)
Gas Standard Volume Total and
Inventory Engineering Units
ENUM Unsigned16 2 S SCF R 0000 = None
1053 = SCF
1521 = Nm3
1526 = Sm3
1531 = NL
1536 = SL
R-2602
69 SNS_GSV_FlowCutoff
(DD Name: Gas Std Vol Flow
Cutoff)
Gas Standard Volume Low Flow
Cutoff
VARIABLE FLOAT 4 S --- R/W Must be >=0.0 R-461-462
70 SNS_ResetGSVolTotal
(DD Name: Reset Gas Std
Volume Total)
Reset Gas Standard Volume
Total (“On” = Reset, “Off” = N/A)
Method Unsigned8 1 S -- R/W 0x00 = No effect
0x01 = Reset
Coil-0063
71 SNS_ResetAPIGSVInv
(DD Name: Reset Gas Std
Volume Inventory)
Reset API/GSV Inventory (“On” =
Reset, “Off” = N/A)
Method Unsigned8 1 S 0x00 R/W 0x00 = No Effect
0x01 = Reset
Coil-0194
72 FRF_StartMeterVer
DD Name: Start On-Line Meter
Verification)
Start On-Line Meter Verification VARIABLE Unsigned8 1 D 0x00 R/W 0x00 = No Effect
0x01 = Start On-Line
Meter Verification
Coil-0190
73 FRF_MV_Index FCF Datalog Index VARIABLE Unsigned16 2 D 0x00 R/W (0-19, 0 = most
recent run)
R-2984
74 FRF_MV_Counter FCF Datalog Item 1: Run Number VARIABLE Unsigned16 2 N-CP 0x00 R R-2985
75 FRF_MV_Status FCF Datalog Item 5: Status
Abort States are compressed to
fit in 3 bits
VARIABLE Unsigned16 2 N-CP 0x00 R Bit7 = FCF pass/fail,
Bits6-4 = state,
Bits3-0 = Abort code
R-2986
76 FRF_MV_Time FCF Datalog Item 2: Time
Initiated (in running seconds)
VARIABLE Unsigned32 4 N-CP 0x00 R N/A R-2987–
2988
77 FRF_MV_LPO_Norm FCF Datalog Item 3: LPO
Normalized Data
VARIABLE FLOAT 4 N-CP 0x00 R N/A R-2989–
2990
78 FRF_MV_RPO_Norm FCF Datalog Item 4: RPO
Normalized Data
VARIABLE FLOAT 4 N-CP 0x00 R N/A R-2991–
2992
79 FRF_MV_FirstRun_Time MV Timers: Time Until First Run
in Hours
VARIABLE FLOAT 4 N-CP 0x00 R/W N/A R-2993–
2994
80 FRF_MV_Elapse_Time MV Timers: Time between each
run after the first run initiated in
hours
VARIABLE FLOAT 4 N-CP 0x00 R/W N/A R-2995–
2996
81 FRF_MV_Time_Left MV Timers: Time left until next
run in hours
VARIABLE FLOAT 4 D 0x00 R N/A R-2997–
2998
Table F-5 Transducer block 1 parameters (continued)
Index Parameter Mnemonic Definition Message
Ty pe
Data Type/
Structure
Size Store
/Rate
(HZ)
Default
Value
Access Enumerated List of
Values / Range
Modbus
Register /
Coil
