158 Model 2700 Transmitter with PROFIBUS-PA
Model 2700 PROFIBUS Block Parameters
CALIBRATION BLOCK
82 SNS_FlowCalTempCoeff
(DD Name: Flow Temp Coeff
(FT))
Temperature coefficient for flow VARIABLE FLOAT 4 S 5.13 R/W >=0.0 R-409-410
83 SNS_MaxZeroingTime
(DD Name: Zero Time)
Maximum zeroing time VARIABLE Unsigned16 2 S 20 R/W 5 to 300 R-0136
84 SNS_AutoZeroStdDev
(DD Name: Zero Std Dev)
Standard deviation of auto zero VARIABLE FLOAT 4 S - R N/A R-0231-232
85 SNS_AutoZeroValue
(DD Name: Zero Offset)
Present flow signal offset at zero
flow in μsec
VARIABLE FLOAT 4 S - R/W -5.0 to 5.0 R-233-234
86 SNS_FailedCal
(DD Name: Zero Failed Value)
Value of the zero if the zero cal
failed
VARIABLE FLOAT 4 S - R N/A R-0235-
0236
87 SNS_K1Cal
(DD Name: Low Density Cal)
Perform low-density calibration METHOD Unsigned8 1 D - R/W 0x00= None
0x01 = Start Cal
Coil-0013
88 SNS_K2Cal
(DD Name: High Density Cal)
Perform high-density calibration METHOD Unsigned8 1 D - R/W 0x00 = None
0x01 = Start Cal
Coil-0014
89 SNS_FdCal
(DD Name: Flowing Density
Cal)
Perform flowing-density
calibration
METHOD Unsigned8 1 D - R/W 0x00 = None
0x01 = Start Cal
Coil-0018
90 SNS_TseriesD3Cal
(DD Name: D3 Density Cal)
Perform third point calibration METHOD Unsigned8 1 D - R/W 0x00 = None
0x01 = Start Cal
Coil-0044
91 SNS_TseriesD4Cal
(DD Name: D4 Density Cal)
Perform fourth point calibration METHOD Unsigned8 1 D - R/W 0x00 = None
0x01 = Start Cal
Coil-0045
92 SNS_K1
(DD Name: K1)
Density calibration constant 1
(μsec)
VARIABLE FLOAT 4 S 1000.
0
R/W 1000 to 50000 R-159-160
93 SNS_K2
(DD Name: K2)
Density calibration constant 2
(μsec)
VARIABLE FLOAT 4 S 50000
.0
R/W 1000 to 50000 R-161-162
94 SNS_FD
(DD Name: FD)
Flowing Density calibration
constant
VARIABLE FLOAT 4 S - R/W >= 0.0 R303-304
95 SNS_TseriesK3
(DD Name: K3
Density calibration constant 3
(μsec)
VARIABLE FLOAT 4 S - R/W 0, or 1000 to 50000 R-0503
96 SNS_TseriesK4
(DD Name: K4
Density calibration constant 4
(μsec)
VARIABLE FLOAT 4 S - R/W 0, or 1000 to 50000 R-0519
97 SNS_D1
(DD Name: D1)
Density 1 (g/cc) VARIABLE FLOAT 4 S - R/W Density Limits (and
<0.05 if T-series)
R-0155-
0156
98 SNS_D2
(DD Name: D2)
Density 2 (g/cc) VARIABLE FLOAT 4 S 1.0 R/W Density Limits, and
must be 1.0+/-0.1 for
T-series
R-0157-
0158
99 SNS_CalValForFD
(DD Name: FD Value)
Flowing Density (g/cc) VARIABLE FLOAT 4 S - R/W >=0 R277-278
100 SNS_TseriesD3
(DD Name: D3)
Density 3 (g/cc) VARIABLE FLOAT 4 S - R/W Density Limits, and
must be at least
+/-0.1 away from D2
and d3 > 0.6 g/cc
R-509
101 SNS_TseriesD4
(DD Name: D4)
Density 4 (g/cc) VARIABLE FLOAT 4 S - R/W Density Limits, and
must be at least
+/-0.1 away from D2
and D3 And d3 <> 0
and d4 > 0.6 g/cc
R-511
102 SNS_DensityTempCoeff
(DD Name: Density Temp Coeff
(DT))
Density temperature coefficient VARIABLE FLOAT 4 S 4.44 R/W -20.0 to 20.0 R-0163-164
103 SNS_TSeriesFlowTGCO
(DD Name: FTG)
T-Series: Flow TG Coefficient
(FTG)
VARIABLE FLOAT 4 S 0.0 R/W N/A R-505
104 SNS_TSeriesFlowFQCO
(DD Name: FFQ)
T-Ser es : Flow FQ Coefficient
(FFQ)
VARIABLE FLOAT 4 S 0.0 R/W N/A R-507
105 SNS_TSeriesDensTGCO
(DD Name: DTG)
T-Series: Density TG Coefficient
(DTG)
VARIABLE FLOAT 4 S 0.0 R/W N/A R-513
106 SNS_TSeriesDensFQCO1
(DD Name: DFQ1)
T-Series: Density FQ Coefficient
#1 (DFQ1)
VARIABLE FLOAT 4 S 0.0 R/W N/A R-515
107 SNS_TSeriesDensFQCO2
(DD Name: DFQ2)
T-Series: Density FQ Coefficient
#2 (DFQ2)
VARIABLE FLOAT 4 S 0.0 R/W N/A R-517
108 SNS_TempCalOffset
(DD Name: Temperature
Offset)
Temperature calibration offset VARIABLE FLOAT 4 S 0.0 R/W N/A R-0413-414
109 SNS_TempCalSlope
(DD Name: Temperature Slope)
Temperature calibration slope VARIABLE FLOAT 4 S 1.0 R/W N/A R-0411-
0412
Temperature Compensation
110 SNS_EnableExtTemp
(DD Name: Enable Disable Ext
Temp)
Enable/Disable External Temp for
API/ED (See 449/450)
Method Unsigned8 1 S 0x00 R/W 0x00 = Disable
0x01 = Enable
Coil-0086
111 SNS_ExternalTempInput
(The data base item is same as
TEMPERATURE – index 29
parameter)
(DD Name: External Temp
calibration input)
External temperature calibration
input
RECORD 101 5 D --- R/W Temp. Sensor Limits R-0449-
0450
Pressure Compensation
Table F-5 Transducer block 1 parameters (continued)
Index Parameter Mnemonic Definition Message
Ty pe
Data Type/
Structure
Size Store
/Rate
(HZ)
Default
Value
Access Enumerated List of
Values / Range
Modbus
Register /
Coil
