NOTICE: Complete Beam Alignment and Aperture Alignment before starting Low Mag Position
mode.
Low Mag Position adjustment is necessary for each Operation Mode. When you
changed Operation mode, you need to adjust it again.
WD (mm)
Lowest magnification
in High Mag Mode
Lowest magnification
in Low Mag Mode
1.5
3500× 35×
2.0
2000× 35×
2.5
1500× 35×
5
700× 35×
12
250× 30×
20
130× 25×
25 or more
100× 20×
NOTICE: If the ABCC Link check box in the Column tab of the Setup dialog window has been
checked, ABCC will start automatically when magnification mode is changed. Image
brightness will be adjusted to adequate value.
