Instruction Manual
IB-106-300NH Rev. 4.3
May 2005
2-4 Installation Rosemount Analytical Inc. A Division of Emerson Process Management
World Class 3000
22.5
o
B
C
8 THREADED HOLES
EQUALLY SPACED ON
D DIA B.C.
ABRASIVE SHIELD
FLANGE O.D.
A
A
TABLE V. ADAPTOR PLATE DIMENSIONS FOR PROBE
TABLE VI. ADAPTOR PLATE DIMENSIONS FOR ABRASIVE SHIELD
DIMENSIONS
IN.
(mm)
DIMENSIONS
IN.
(mm)
ANSI
(P/N 4512C34G01)
ANSI
(P/N 3535B58G02)
DIN
(P/N 4512C36G01)
DIN
(P/N 3535B58G06)
JIS
(P/N 4512C35G01)
JIS
(P/N 3535B58G04)
"A"
"A"
"B"
THREAD
"B"
DIA
"D"
DIA
"C"
DIA
"C"
THREAD
6.00
(153)
9.00
(229)
0.625-11
4.75
(121)
7.50
(191)
4.75
(121)
0.625-11
7.5
(191)
9.25
(235)
(M-16 x 2)
3.94
(100)
7.48
(190)
5.708
(145)
(M-16 x 2)
6.50
(165)
9.25
(235)
(M-12 x 1.75)
4.92
(125)
7.894
(200)
5.118
(130)
(M-20 x 2.5)
NOTE: PART NUMBERS FOR ADAPTOR PLATES INCLUDE
ATTACHING HARDWARE.
NOTE: PART NUMBERS FOR ADAPTOR PLATES INCLUDE
ATTACHING HARDWARE.
ADAPTOR PLATE FOR 3, 6, 9,
AND 12 FT ABRASIVE SHIELD
INSTALLATIONS. SEE SHEET 2.
CROSSHATCHED AREA IN 4
CORNERS MAY BE USED TO
PROVIDE ADDITIONAL HOLES FOR
FIELD BOLTING OF PLATE TO
OUTSIDE WALL SURFACE.
ADAPTOR PLATE FOR
STD WORLD CLASS 3000
PROBE INSTALLATION.
SEE SHEET 1.
4 STUDS,
LOCKWASHERS AND
NUTS E
QUALL
Y
SPACED ON
C DIA B.C.
A
A
2.500 DIA
45
o
C
B
16860021
Figure 2-1. Probe Installation (Sheet 3 of 5)
