Instruction Bulletin
Appendix B Rev. 2.3
May 2005
Rosemount Analytical Inc. A Division of Emerson Process Management Appendices B-11
World Class 3000
LEGEND FOR FIGURE B-7
1. Enclosure Cover
2. Screw
3. Lockwasher
4. Terminal Cover
5. Stand Off
6. Lockwasher
7. Daughter Board
8. Terminal Cover
9. Screw
10. Stand Off
11. Hex Nut
12. Mother Board
13. Fuse
14. Subplate
15. Enclosure Box
16. Lockwasher
17. Stand Off
18. Screw
19. Lockwasher
20. Mounting Plate
21. Screw
22. Gasket
23. Transformer
24. Retaining Plate
25. Hex Nut
REPLACEMENT PARTS
Table B-2. Replacement Parts for Heater Power Supply
FIGURE and INDEX NO. PART NUMBER DESCRIPTION
Figure B-1
Figure B-1
Figure B-1
Figure B-1
Figure B-1
Figure B-1
Figure B-7, 13
Figure B-7, 12
Figure B-7, 7
Figure B-7, 23
Figure B-7, 23
3D39129G01
3D39129G02
3D39129G03
1U05667G01
1U05667G02
1U05667G03
1L01293H02
3D39080G02
3D39078G01
1M02961G01
1M02961G02
Non-Hazardous HPS (120 Vac)
Non-Hazardous HPS (100 Vac)
Non-Hazardous HPS (220, 240 Vac)
Explosion-Proof HPS (120 Vac)
Explosion-Proof HPS (100 Vac)
Explosion-Proof HPS (220, 240 Vac)
Fuse, 5 A @ 250 Vac, anti-surge, case
size; 5 x 20 mm, type T to IEC127,
Schurter
Mother Board
Daughter Board
Transformer (120, 220, 240 Vac)
Transformer (100 Vac)
