Instruction Bulletin
Appendix J Rev. 1.2
May 2005
Rosemount Analytical Inc. A Division of Emerson Process Management Appendices J-1
World Class 3000
APPENDIX J, REV 1.2
HART COMMUNICATOR MODEL 275/375
IFT 3000 APPLICATIONS
DESCRIPTION
J-1 COMPONENT CHECKLIST OF TYPICAL
HART
®
COMMUNICATOR PACKAGE
A typical Model 275D9E HART
®
Communicator
package should contain the items shown in
Figure J-1, with the possible exception of op-
tions. If a rechargeable NiCad battery pack has
been selected, at least one spare battery pack
(per HART Communicator) is recommended.
J-2 UNIT OVERVIEW
a. Scope
This Instruction Bulletin supplies details
needed to install and operate the HART
®
Communicator in relation to the World Class
3000 Intelligent Field Transmitter. Informa-
tion on troubleshooting the communicator is
also included.
1
2
3
4
5
6
7
o
HART
Communicator
FISHER-ROSEMOUNT
TM
MAN 4275A00
English
October 1994
8
9
10
686001
1. Lead Set (with Connectors)
2. Carrying Case
3. Communicator
4. AA Alkaline Battery Pack, or Rechargeable
NiCad Battery Pack (Option)
5. Memory Module
6. Belt Clip (with screws)
7. Hanger (mounts on belt clip, Option)
8. Pocket-sized Instruction Bulletin
9. PC Interface Adaptor (Option)
10. Load Resistor, 250 W (Option)
Figure J-1. Typical HART
®
Communicator Package, Model 275D9E
